Infinity Tugs
Discovery HElectric helicopter tug for skid-equipped light helicopters
Overview
DISCOVERY H is an electric helicopter tug for skid-equipped light helicopters such as the Robinson R44. At just 11 cm tall, it slides straight under the skid; the telescopic attachment arm takes hold, and the 48 V, 900 W drive lifts and tows up to 2,500 kg at up to 5 km/h. One person handles the whole ground move, from hangar to pad, on grass or asphalt — no ground-handling wheels, no extra hands. Like every Infinity Tug, it is built by pilots and engineers around a fiberglass hull, with a manual winch integrated into the Infinity Tugs handle.
Compatible Aircraft
Compatible with skid-equipped light helicopters such as the Robinson R44.
Use Cases
DISCOVERY H is for the operator of a skid-equipped light helicopter — a Robinson R44 or similar — who currently needs ground-handling wheels and two or three people for every move off the pad. Instead, it slides under the skid at just 11 cm tall, the telescopic arm takes hold, and the 48 V drive lifts and tows up to 2,500 kg at up to 5 km/h. One person does the whole ground move: out of the hangar to the pad before a flight, back inside afterwards, or repositioning for a wash or maintenance — on grass or asphalt, at a controlled walking pace.
How It Compares
Against traditional ground-handling wheels, DISCOVERY H removes the manual lifting and the crew: no jacking the skids by hand, no team heaving the aircraft across the apron — one person lifts and drives under power. Against a manual skid dolly, the electric drive gives you controlled, repeatable moves on inclines and hangar thresholds rather than relying on how hard the crew can push. And because it's electric, it's quiet and clean enough to run inside a closed hangar with the doors down.
Specifications
| Motor | Electric 48 V / 900 W |
|---|---|
| Dimensions | 210 × 83 × 11 cm |
| Weight | 95 kg |
| Towing capacity | 2,500 kg |
| Max load on ramp | 500 kg |
| Speed | Up to 5 km/h |
| Battery | 48 V 11 Ah Li-Ion |
Equipment
Standard Equipment
- Infinity Tugs handle with manual winch
- Control panel
- Telescopic attachment arm
- Fiberglass hull
- Standard color white
- Suitable for grass and asphalt
Optional
- Carbon hull
- LED bar
- Extended battery
- Custom colors
- Solar charging (coming soon)
- GPU (coming soon)
Frequently Asked Questions
- Which helicopters does DISCOVERY H fit?
- Skid-equipped light helicopters such as the Robinson R44, up to 2,500 kg. Tell us your type and we'll confirm the fit.
- How does it attach to the skids?
- At just 11 cm tall it slides straight under the skid, and a telescopic attachment arm takes hold and lifts — no separate ground-handling wheels needed.
- Can one person move the helicopter alone?
- Yes. It lifts and tows up to 2,500 kg at up to 5 km/h under electric power, so a single operator handles the whole move from hangar to pad.
Request a Quote
Request a Quote
Tell us what you fly and how you move it today. We will come back with the right configuration and a quote for your operation.
